  • 0/1-10V Dimmable LED Driver
  • Triac Dimmable LED Driver

Mini 30W 36W Non-Flicker 0-10V Dimming LED Driver Power Supply

Mini 30W 36W Non-Flicker 0-10V Dimming LED Driver Power Supply

Product Introduction

Features:
1-classive two polar electronic design, high quality
2-Small size, isolated LED Driver
3-Gel injected type, withstand high temperature & high humidity.
4-flicker-free by shooting,0/1-10V dimming
5-TUV/CE Certificated, Meet the ENEC/UL/SAA
Mechanical Specification
1. Casing material : PC,94V-0,125°C
2. Dimension:
    L*W*H : 53.5*42*23.5mm (No fixed holes)
    L*W*H : 69*42*23.5mm (With fixed holes )
    (P.S: No fixed holes is normal type for order, if needed fixed holes, please tell       us when you place the order.)

Application:
Commercial light: Spot light, track light, down light
Mini lamps used in museums, hotels, villas,etc lighting projects.




Specification

Installation Type: Built-in type.
Dimming Type: 0-10V/1-10V Dimming or Non-Dimming.
please inform us your dimming type when inquiry, thank you.

ModeO.PI.V (Vac)O.V (Vdc)O.C (mA)PFEf. Current AccuracyTaTcRemarks
(W)
RMS-36-900AS29.4100-2778-42700>0.987%<5%60°C90°CTUV/CE
31.5750>0.987%<5%
328-40800>0.988%<5%
36900>0.988%<5%
368-381000>0.988%<5%
